15'' Neodymium Coaxial PA Speaker

Guangzhou Huiyin Audio Co., Ltd.
Contact Now

15'' Neodymium Coaxial PA Speaker

  • 1
  • 2
  • 3

Place of Origin : Guangdong, China

Brand Name : OEM

Model Number : HYW-1575-077

Supply Ability : 50000 Piece/Pieces per Month

Packaging Details : 1. Inside + outside strong double boxes 2. Customized

MOQ : 2 Piece/Pieces

Price : $90.00 - $110.00 / Piece

Type : Coaxial speaker

Nominal diameter : 15 inch

Frequency response : 44Hz-20KHz

Max power handling : 1000W

RMS Power handling : 500W

Sensitivity : 100dB

Magnet material : Neodymium

LF Voice coil diameter : 75mm/3 inch

HF Voice coil diameter : 75mm/3 inch

Impedance : 8 ohm

Power : 500W

Frequency Range (Hz) : 44hz-20khz

Port : Huangpu port, Guangzhou

Contact Now

15 inch neodymium coaxials professional speaker carbon cone Coaxial speaker

Product Description



Features:

  • 15 inch Coaxial speaker with neodymium magnet
  • 500Wrms power handling , 1000W max power
  • Carbon cone for high performance
  • 44hz- 20kHz frequency response
  • 100dB sensitivity
  • Inside/Outside copper voice coil



Specification
Nominal diameter
380/15
mm/inch
Nominal impedance
8
ohm
Min impedance LF
5.2
ohm
Min impedance HF
6
ohm
Frequency response
44hz-20khz
Hz
  RMS Power
500

Magnet material
 Neodymium
Specification LF
Sensitivity (1w/1m)
100
dB
Nominal power handling
500
Watts
Continuous power handling
1000
Watts
Voice coil diameter
75/3
mm/ inch
Winding material
Copper

Cone material
Carbon

Surround material
Cloth

Specification HF
Sensitivity (1w/1m)
112
dB
Nominal power handling
100
Watts
Continuous power handling
200
Watts
Voice coil diameter
75/3
mm/inch
Diaphragm
Titanium

T/S Parameter
Fs
44.2
Hz
Re
5.2

Qes
0.7258
Qts
0.6449
Qms
5.7878
Vas
142.3946
L
Rms
4.7353
kg/s
Cms
0.1313
mm/N
Mms
98.59
gr
Sd
0.0881
Mounting information
Overall diameter
388/15.3
mm/inch
Bolt Circle diameter
371/14.6
mm/inch
Baffle Cutout diameter
358/14
mm/inch
Total Depth
195/7.7
mm/inch
Shipping information
Net weight
6
KG
Shipping weight
7
KG
Shipping box
420x420x220
mm
